Automatic test box

automatic test box icon 1

Series

Automatic test box (433 x 440 x 313 mm)
    • An ideal solution for bluetooth, wifi, 3G, 4G testing
    • High isolation
  • Easy & Flexible operation

Technical specifications
Frequency (Hz) 0.8~6 GHZ
Isolation ≥75 dB @ 2.4 GHz
≥70 dB @ 5.8 GHz
Radio frequency interface SMA*4
Data interface See our Filter modules for shielded boxes
AC power requirements AC 110-220 V / 50-60 Hz
Work size (mm) 433(W)*440(D)*313(H)
Outer dimensions (mm) 530(W)*562(D)*395(H)
Box body material coll plated, surface paint
Weight (kg) 30 kg
Working temperature (°C) 0-50
Appearance color Beige
* Notice: dimensions are indicative
Features
  • High levels of shielding attenuation, greater than 75 dB
  • Box can be equipped with shielded power filters for power
  • Connection in the box while still blocking all wireless signals.
  • Easy & Flexible operation in Lab and production line
  • R&D, custom design

Technical drawing
Automatic test box technical drawing
