Aluminium tape was developed especially for EMI/RFI shielding/screening in Aluminium housings and frames to prevent galvanic corrosion.

We not only produce our Aluminium tape on rolls, but also die-cut according to the customer's drawing on strips or in pieces (as stickers), both with or without self-adhesive.

Technical specification and part numbers
Part number
(with conductive adhesive)
Part number
(with standard adhesive)
Foil material Aluminium
Surface Shiny
Foil thickness 0.040 mm
Total thickness 0.065 mm
Adhesive Synthetic conductive resin
Adhesive performance 4.5 N/cm
Tensile strength 25 N/cm
Temperature resistance 155 °C
El. resistance through adhesive 0.003 Ohm
Standard roll widths (mm)* 10, 25, 50, 100
Roll lengths* 16.5 m
These values are measured under laboratory conditions.
In other situations results may differ; please read our Guarantee.
cut in any shape or size

technical drawing
conductive aluminium tape construction
