Elektrisch geleidende schuimtape

Serie

Geef de dikte op in mm inclusief soorten plakband
De maximale breedte bedraagt ​​100 mm
De maximale lengte 10 meter

Conductive Foam tape conducts electricity both horizontally and vertically.

Conductive Foam tape is better than plated sponge and comes with less powder detachment when cutting, friction and repeating compression.

Conductive foam tape is easy to attach to objects due to electrically conductive adhesive tape on the bottom and easy for converting due to roll supply.

Thickness of the conductive foam tape is 0.3, 0.4 and 0.5 mm.

Technical details
Subject Unit 5776 Series
Material - Copper and nickel plated non woven + polyurethane foam + adhesive
Color   Grey
Temperature °C -10 ~ 80 °C (Depend on adhesive tape type)
Thickness mm 0.3, 0.4 and 0.5 mm
(Thickness including adhesive tape types)
Max. width mm 100
Max. length m 10
Resistance
(Top to bottom)		 Ω Typical. 0,1 Ω
Surface Resistance Ω/□ Typical. 0.1 Ω/□
Recommended
Compression		 % Max. 50% of original height
Compression Force kgf/cm² Max. 1.0 (compress 40% of original height)
Properties
  • Highly compressible with minimal force, good resilience, fast recovery
  • Pass salt water and corrosion resistance test
  • Halogen Free, EU-RoHS, thermal resistance
  • Easy to die cut and convert due to roll type product
  • Minimal dust and metal powder detachment for external friction, repeating compression, handling and production
  • Good electric conduction horizontally and vertically
Applications
  • EMI Shielding
  • EMI Grounding
  • EMI Wall
  • EMI Gasket
  • EMI Tape
  • Electric connector
  • etc
