De gewenste breedte van de rol. Standaard rolbreedtes: 10, 25, 50, 100 mm.
Geef de lengte op in meters

This contact-surface tape is used to improve the corrosion resistance of construction metals (like untreated steel plates), or to improve galvanic compatibility when 2 metal parts are connected with a gasket. After the parts have been coated, the paint overlaps the metal tape to increase the bonding.

Technical specification and part numbers
Part number
(with conductive adhesive)
Part number
(with standard adhesive)
Construction Contact surface tape 3304
Foil material Soft copper
Surface Shiny
Foil thickness 0.035 mm
Total thickness 0.060 mm
Adhesive Synthetic conductive resin
Adhesive performance 4.5 N/cm
Tensile strength 55 N/cm
Temperature resistance 155 °C
El. resistance through adhesive 0.003 Ohm
Standard roll widths (mm)* 10, 25, 50, 100
Roll lengths* 16.5 m
These values are measured under laboratory conditions.
In other situations results may differ; please read our Guarantee.

Metal tape with a highly conductive self-adhesive on one side and masking tape on the other side

Contact Surface Tape Technical drawing
Technical drawing
Contact Surface Tape construction
