Frameless Honeycomb ventilation panels

frameless honeycomb vent panels icon 1

Series

Please note: Specify the outer dimension in mm.
Please note: Specify the outer dimension in mm.
Allowed maximum size is 64 MiB. You can upload multiple files

Honeycomb vents are used to EMI shield openings for ventilation or acoustic/visual contact. We can make these vents according to your drawing within a few days, or you can use our standard range from stock.

Honeycombs are also frequently used as flow straighteners to create a laminar flow.


Dimensions

Frameless honeycomb ventitation panels can be produced very accurately in any desired size. Specify the dimensions you want in the how to order section above.


Available types



Frameless honeycomb vents panels available types
Benefits
  • Light weight
  • High shielding performance
  • Low air-flow resistance
  • Reduction of turbulance
  • Can be made round or rectangular shaped

Honeycomb material thicknesses

We manufacture Honeycomb material in thicknesses of 6.35, 12.7 and 26 mm.

Frameless honeycomb vents panels material thicknesses
Compressed sides

The 9505 series Frameless Honeycomb ventilation panels can be made with compressed sides. This has the advantage that the ventilation panel easily remains in place in the opening of your electronics housing. This also provides better shielding performance.

Frameless honeycomb vents panels compressed sides
