Desktop measurement box with ventilation

desktop measurement box with ventilation icon 1

Series

Desktop measurement box with ventilation (515 x 550 x 515mm)

By default, this box comes with 6 shielded SMA penetrations. The box comes with 2 fans. Many other shielded conduits are available on request. They may optionally also be added later.


Technical specifications
Optional data interface See our filter modules
Radio frequency interface SMA*6
Numbers of possible filters 6 pcs
Work size (mm) 480 (W) * 490 (D) * 480 (H)
Appearance size (mm) 550 (W) * 650 (D) * 535 (H)
Weight (kg) Ca. 40
Working temperature (°C) 0-50
Shielding effect ≥70 dB @ 2.4 GHz/5.8 GHz)
Appearance color Beige
* Notice: dimensions are indicative
Features
  • Wireless communication test system
  • For Bluetooth, WiFi, 3G, wireless test, RFID
  • High levels of shielding attenuation, greater than 65 dB
  • Easy & Flexible operation in Lab and production line
  • R&D, custom design
  • Box can be equipped with shielded power filters for power connection in the box while still blocking all wireless signals.

Technical drawing
desktop measurement box with ventilation technical drawing
